Download: Brouchure | Installation Guide | Hitachi Finger Vein Module

CSS-722

Finger vein recognition access controller, which is next generation biometric technology. The technology enables the device can be applied in high security environments such as bank and government agencies. Finger vein controller features an IP65 certified weatherproof exterior.
IP65 protection allows system designers to place the terminal in both indoor and outdoor environments. It design either access control and Time attendance. CSS-722 also has built-in friendly web server, and it integrated with our SOMAC centralized software.

Finger Vein Recognition Access Control Terminal with Hitachi Finger Vein module

FEATURES HIGHLIGHTS

• 400 sets of function key.
• Anti-pass back / Anti duress.
• Basic Time attendance (First IN / Last OUT).
• Color screen with touch keypad.
• LOGs data real time PUSH.
• Indoor and outdoor use (IP65 certificated).
• Standalone, Web-Based Management and network capability.
• Support DHCP for easy setup.

GENERAL DATA

• Software Application: SoMac / Browser
• Verification Mode: Fingervein / Card / PIN / Match on card
• Proximity: EM / Mifare / HID
• Fingervein Module: HITACHI H1EAX (ISO/IEC 19795-1)
• Fingervein Template Capacity: 12,000
• 1:1 Verification Time: 1 sec
• 1:1,000 Identification Time: 1.5 sec
• FAR (False Acceptance Rate): 0.01%
• FRR (False Rejection Rate): 0.0000067%
• User Capacity: 10,000
• Function Keys: 400 SET
• Time Sets / Time Zones / Group: 255 / 120 / 255 SET
• Holiday Dates: 100 SET
• Access&Event Logs / System Logs: 65536 / 2688
• Inputs: 3 Inputs, (1) Exit button
• Relay Outputs: 1 output for Lock (COM / NO / NC)
• Web Base Management: Yes
• Support real time log: Yes
• PUSH methodology: Yes
• Wiegand Inputs: 26/34 bits Wiegand reader
• IP Mode: Static IP / AUTO IP (DHCP Client)
• LED Indicators: 3 Colours (RGB)
• Speaker Indication: Optional
• Buzzer: Single Tone
• TFT Color LCD : 2.8"
• Capacitive Touch Keys: 4 x 4
• Anti-Tampering Switch: Yes

COMMUNICATION DATA

• TCP / IP: 10 / 100 Base-T
• Wiegand: 26 / 34 bits

ELECTRICAL DATA & CONDITIONS

• Power Consumption: 500 mA ± 5%
• Operation Voltage: 9 ~ 24VDC / 1A
• Output Relay: 30VDC, 1A
• Operation Temperature: 0°C ~ 50deg;C
• Operation Humidity: 5% ~ 80% RH

PHYSICAL DATA

• Dimension (mm): 120 x 235 x 85
• Weight: 0.7 kg
• Installation: Indoor / Outdoor (IP65 weatherproof)

INTERNATIONAL STANDARDS & WARRANTY

• Certification: CE, FCC, ROHS
• Warranty: 2 Years (Fingerprint module: 1 year)

REMARKS

• Web Server, supported by Chiyu Technology's SOMAC Central management software. Access Control and Time & Attendance. Features like anti-passback, user accession, group accession, door setup by verification methods
• All products with 2 years warranty.

Download: Brochure | User Manual | Quick User Guide

PFace202 multi-biometric time & attendance and access control terminal supports up to 600 palm templates, 1,200 face templates, 2,000 fingerprint templates and 10,000 cards (optional).
With ZKTeco latest hardware platform and ZKFace, ZKFinger, ZKPalmVein algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience.
With advanced palm & face algorithm and multi-biometric verification technology, the terminal's security level of verification is significantly enhanced.

Read More

BioSense III : Finger Scan Access Control Standalone Terminal

Download : Finger Scan & Card Brochure | Finger Scan & Card Installation Guide | Finger Scan & Card Web User Manaual

Finger Scan Access Controller for doors and time attendance clcok machine with fingerprint security through web based. Ideally, BF630W features standard TCP/IP and RS485 interfaces for main communication between devices and the server.

It also supports USB/Voice and Wiegand interfaces to provide maximum versatility.
BF630W has optional WiFi and 4G and Power-over-Ethernet for flexible installation.

 Fingerprint Recognition Security Access Control and Time & Attendance terminal.

FEATURES HIGHLIGHTS

• Access Control / Attendance Management two in one using Finger Scan or Card.
• Web Server Management as well as Software package provide.
• TCP connection, single door to multi-door management become possible.
• IP Camera integrated can be live monitoring when system users punched.

PRODUCT SPECIFICATION

• Verification Mode: FP / Card / Password
• Software Application: SoMac
• Template Capacity: 9,590
• Sensor Type: Optical
• Resolution: 500dpi
• Sensing Area: 16 x 19mm
• Template Size: 256 ~ 384 Bytes
• Image Size: 272 x 320 (pixel)
• 1:1 Verification time: < 600msec
• 1:1000 Identification time: < 760msec
• Card Capacity: 20,000
• Communications: TCP/IP, Wiegand/RS485
• DIO Support: DI: 3 / DO: 2
• Inbuilt Relays (Max power requirement): Lock / Ring (0.5A, 120VAC / 1A, 30VDC)
• Option: USB / Voice
• System Log: 1,536 entries
• Entry Log: 51,968 entries
• Time Set / Time Zone / Group: 255 / 120 / 255 Sets
• Holiday / Rin Settingg: Yes / Yes
• Remote Control / Event Handle: Yes / Yes
• Multiple Badge / Fast Registry: 10 Groups / Yes
• Function Key: 400 (Auto / Manual)
• Anti-Pass Back / Anti Duress: Yes / Yes
• Power Consumption: 780mA ± 5%
• Power Requirement: 9 ~ 24VDC / 1A
• Operation Temperature: 0°C ~ 65°C
• Operation Humidity: 5% ~ 80% RH
• Dimension / Weight: 160.2 x 140.2 x 46.7mm / 501g

REMARKS

• Web Server, supported by Chiyu Technology's SOMAC Central management software. Access Control and Time & Attendance. Features like anti-passback, user accession, group accession, door setup by verification methods
• All products with 2 years warranty.

Download: Brochure | User Manual | Quick User Guide

PFace202 multi-biometric time & attendance and access control terminal supports up to 600 palm templates, 1,200 face templates, 2,000 fingerprint templates and 10,000 cards (optional).
With ZKTeco latest hardware platform and ZKFace, ZKFinger, ZKPalmVein algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience.
With advanced palm & face algorithm and multi-biometric verification technology, the terminal's security level of verification is significantly enhanced.

Read More

Facial Recongnition Time Attendance and Access Control Terminal (Technology by Hanvon | FaceGo)

Download: Brochure | Installation Guide

 BIOSENSE FA1 (Face GO F910)

Facial recognition Access Control Terminal can apply both on Access control and Time attendance. With its user friendly and high security, accompanied by Robust Performance feature, make this Face Access Controller more reliable in the Market.

 Why Face?

Hanvon Facial Recognition Technology

From 2003, with more than 10 years of study and experience in the pattern recognition area, Hanvon decided to dedicate on the facial recognition field and carried out study and research on the facial recognition technology. After 5 years, we developed “Dual Sensor™” facial recognition algorithm which Hanvon has completely independent intellectual property rights, the basic principles are as below:

“Dual Sensor™” adopts two special cameras which just like a person’s eyes. This technology not only remains the advantages of 2D facial recognition, but also combines part information from 3D facial recognition. “Dual Sensor™” has fast identification speed and highly accurate recognition rate, and its capacity researches to the world class. “Dual Sensor™” has laid a solid foundation for large scale of application of facial recognition.

Read More

Download: Brochure | User Manual | Quick User Guide

PFace202 multi-biometric time & attendance and access control terminal supports up to 600 palm templates, 1,200 face templates, 2,000 fingerprint templates and 10,000 cards (optional).
With ZKTeco latest hardware platform and ZKFace, ZKFinger, ZKPalmVein algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience.
With advanced palm & face algorithm and multi-biometric verification technology, the terminal's security level of verification is significantly enhanced.

Read More
